Portable Standing Seam Roll Forming Machine
Beenew’s Portable Standing Seam Roll Forming Machine boasts a compact, portable design that facilitates easy transportation and on-site manufacturing. This mobility is particularly advantageous for extensive construction projects where the ability to move around is paramount.
The machine’s versatility shines through its capacity to process both aluminum and PPGI steel sheets, catering to a wide range of roofing needs. Aluminum provides a lightweight and corrosion-resistant option, whereas PPGI steel offers robust durability and a plethora of color choices for enhanced aesthetic appeal.
Crafted from GCr15, a premium bearing steel renowned for its hardness and wear resistance, the forming rollers ensure robust performance. An additional hard chrome coating further bolsters the rollers’ durability and offers exceptional rust protection, guaranteeing long-term, reliable service
Machine Parameters
| Item | Value |
| Driving Motor | 4KW |
| Forming Station | 8 |
| Roller Material | GCr15 |
| Shaft Diameter | 40mm |
| Shaft Material | 45# steel |
| Pump Motor | 2.2KW |
| Frame Type | Common weld wall |
| Cutting Type | Hydraulic Cutting |
| Control System | PLC |
| Main Electric Parts Brand | Simenz, Delta, Omron or Schneider |
| Cutting Length Precision | ±2mm |
| Machine Dimension | 2800*750*1350mm |
| Electric Standard | 380V/50HZ/3Ph or customized |
| Paint Color | Grey White+Bule or customized |
